Masung MS-TS101, Thermal Transfer & Direct Thermal Label Printer for Integration
Dual Printing Modes: Supports both thermal transfer and direct thermal printing for versatile label applications.
High-Speed & Accurate: Prints up to 120mm/s at 203dpi with multiple sensors for precise alignment and positioning.
Wide Media Compatibility: Works with continuous paper, copperplate, tags, synthetic paper, and labels 20–112mm wide.
Durable & Reliable: Carbon ribbon support up to 300 meters, a robust cutter with up to 1 million cuts, and low-noise operation.
High-Speed & Accurate: Prints up to 120mm/s at 203dpi with multiple sensors for precise alignment and positioning.
Wide Media Compatibility: Works with continuous paper, copperplate, tags, synthetic paper, and labels 20–112mm wide.
Durable & Reliable: Carbon ribbon support up to 300 meters, a robust cutter with up to 1 million cuts, and low-noise operation.
| Quantity: | |
|---|---|
-
MS-TS101
-
MASUNG
High-Quality Thermal Printing
The MS-TS101 is a professional thermal transfer and direct thermal printer designed for clarity and precision. With a maximum print width of 104mm and 203dpi resolution, it delivers crisp barcodes, QR codes, text, and graphics. Advanced sensors—including black mark detection, gap detection, and ribbon end sensors—ensure accurate alignment and hassle-free maintenance.
Fast and Efficient Operation
Achieve rapid printing speeds of up to 120mm/s, making the MS-TS101 ideal for high-volume labeling in retail, fashion, hospitality, healthcare, and financial sectors. The printer’s large paper tray and adjustable paper stop simplify media loading, while the full/partial cutter accommodates label thickness from 0.06mm to 0.25mm.
Versatile Media and Barcode Support
Compatible with continuous and gap labels, tags, copperplate, and synthetic papers, this printer handles media widths from 20–112mm. It supports a wide range of barcodes, including UPC-E, JAN8/JAN13 (EAN), CODE39, ITF, CODABAR, CODE128, and 2D QR codes, ensuring seamless integration into inventory, shipping, and product labeling workflows.
Compact, Durable Design
Weighing only 2.45kg and measuring 196mm × 184mm × 151mm, the MS-TS101 is compact yet sturdy. It features RS232 and USB interfaces, operates in temperatures from -10°C to 50°C, and can handle humidity up to 85%RH, providing reliable performance across various industrial and commercial environments.
| Parameter | Specification |
|---|---|
| Model | MS-TS101 |
| Resolution | 203dpi |
| Printing Method | Thermal Transfer |
| Print Width | 104mm (max) |
| Print Speed | 120mm/s (max) |
| Max Paper Roll Diameter | 120mm (max) |
| Ribbon | 300 meters, outer diameter 67mm (max), 1" ribbon core (external) |
| Ribbon Width | 40mm ~ 110mm |
| Sensors | Gap Detection Sensor, Black Mark Sensor, Ribbon End Sensor, Printhead Lift Sensor |
| Paper Type | Continuous paper, gap labels, etc. (outside roll print) |
| Paper Width (Label + Backing) | 20 ~ 112mm |
| Cutting Method | Full Cut / Partial Cut |
| Gap Between Labels | 2mm (min) |
| Paper Feeding | Manual Feed |
| Cutter | Allowed Paper Thickness: 0.06mm ~ 0.1mm, 0.1mm ~ 0.25mm; Cutter Lifespan: 1,000,000 cuts¹, 500,000 cuts² |
| Paper Thickness | 0.06 ~ 0.25mm |
| Baud Rate | 9600, 19200, 38400, 115200 |
| Supported Barcodes | UPC-E, JAN13 (EAN13), JAN8 (EAN8), CODE39, ITF, CODABAR, CODE93, CODE128, Standard ENA13, QR Code, etc. |
| Power Supply | DC 24V ±10% |
| Average Current | 2A @ DC24V (24% print density) |
| Peak Current | 6A |
| Communication Interface | RS232 / USB |
| Operating Temperature | -10 ~ 50℃ (non-condensing) |
| Operating Humidity | 20% ~ 85% RH (85% RH at 40℃) |
| Dimensions | Approx. 196mm × 184mm × 151mm |
| Weight | 2.45kg (including ribbon, excluding paper roll) |
High-Quality Thermal Printing
The MS-TS101 is a professional thermal transfer and direct thermal printer designed for clarity and precision. With a maximum print width of 104mm and 203dpi resolution, it delivers crisp barcodes, QR codes, text, and graphics. Advanced sensors—including black mark detection, gap detection, and ribbon end sensors—ensure accurate alignment and hassle-free maintenance.
Fast and Efficient Operation
Achieve rapid printing speeds of up to 120mm/s, making the MS-TS101 ideal for high-volume labeling in retail, fashion, hospitality, healthcare, and financial sectors. The printer’s large paper tray and adjustable paper stop simplify media loading, while the full/partial cutter accommodates label thickness from 0.06mm to 0.25mm.
Versatile Media and Barcode Support
Compatible with continuous and gap labels, tags, copperplate, and synthetic papers, this printer handles media widths from 20–112mm. It supports a wide range of barcodes, including UPC-E, JAN8/JAN13 (EAN), CODE39, ITF, CODABAR, CODE128, and 2D QR codes, ensuring seamless integration into inventory, shipping, and product labeling workflows.
Compact, Durable Design
Weighing only 2.45kg and measuring 196mm × 184mm × 151mm, the MS-TS101 is compact yet sturdy. It features RS232 and USB interfaces, operates in temperatures from -10°C to 50°C, and can handle humidity up to 85%RH, providing reliable performance across various industrial and commercial environments.
| Parameter | Specification |
|---|---|
| Model | MS-TS101 |
| Resolution | 203dpi |
| Printing Method | Thermal Transfer |
| Print Width | 104mm (max) |
| Print Speed | 120mm/s (max) |
| Max Paper Roll Diameter | 120mm (max) |
| Ribbon | 300 meters, outer diameter 67mm (max), 1" ribbon core (external) |
| Ribbon Width | 40mm ~ 110mm |
| Sensors | Gap Detection Sensor, Black Mark Sensor, Ribbon End Sensor, Printhead Lift Sensor |
| Paper Type | Continuous paper, gap labels, etc. (outside roll print) |
| Paper Width (Label + Backing) | 20 ~ 112mm |
| Cutting Method | Full Cut / Partial Cut |
| Gap Between Labels | 2mm (min) |
| Paper Feeding | Manual Feed |
| Cutter | Allowed Paper Thickness: 0.06mm ~ 0.1mm, 0.1mm ~ 0.25mm; Cutter Lifespan: 1,000,000 cuts¹, 500,000 cuts² |
| Paper Thickness | 0.06 ~ 0.25mm |
| Baud Rate | 9600, 19200, 38400, 115200 |
| Supported Barcodes | UPC-E, JAN13 (EAN13), JAN8 (EAN8), CODE39, ITF, CODABAR, CODE93, CODE128, Standard ENA13, QR Code, etc. |
| Power Supply | DC 24V ±10% |
| Average Current | 2A @ DC24V (24% print density) |
| Peak Current | 6A |
| Communication Interface | RS232 / USB |
| Operating Temperature | -10 ~ 50℃ (non-condensing) |
| Operating Humidity | 20% ~ 85% RH (85% RH at 40℃) |
| Dimensions | Approx. 196mm × 184mm × 151mm |
| Weight | 2.45kg (including ribbon, excluding paper roll) |
