MS-D247
MASUNG
The MS-D247 uses dot-line thermal printing technology and a 432-dot print line to produce clear text, receipts, and ticket information at speeds of up to 200 mm/s. With a maximum print width of 54 mm and compatibility with 58 ± 0.5 mm thermal paper, it is designed for compact receipt and ticket printing applications. Its support for multiple character formats, including ASCII and Chinese character sets, helps accommodate different languages and printing layouts.
To support unattended operation, the MS-D247 integrates automatic paper loading with sensors for printhead temperature, printhead switch status, paper-out detection, and cutter detection. Black mark detection and paper output detection can also support positioning and paper-handling requirements when included in the configured model. These functions help reduce manual intervention and improve operational continuity in ATMs, ticket kiosks, and other automated dispensing equipment.
The built-in cutter supports both full cutting and partial cutting, allowing equipment manufacturers to select a suitable paper separation method for different applications. Automatic cutting helps streamline receipt and ticket collection while reducing the need for manual tearing. With a specified printing life of up to 100 km, the MS-D247 is designed for repeated printing in commercial environments such as fuel stations, ticket vending locations, and self-service payment terminals.
Measuring approximately 91.4 × 52 × 97.5 mm and weighing around 135 g, the MS-D247 is suitable for embedded installation where internal equipment space is limited. Its serial communication interface and 24 V ±10% operating voltage support integration into compatible host systems. The printer supports Windows XP, Windows 7, Windows 8, Windows 10, Android 4.0 and above, and Ubuntu, subject to interface compatibility, driver availability, and system integration requirements.
The Masung MS-D247 58mm thermal kiosk printer is suitable for ATM receipt printing, ticket vending machines, fuel dispensers, coupon machines, self-service payment terminals, and other automated kiosks. Its high-speed thermal printing, automatic paper feeding, integrated cutter, and barcode and QR code capabilities make it a practical option for equipment manufacturers developing unattended printing systems. As a B2B printer manufacturer, Masung can discuss OEM/ODM customization requirements, including mechanical mounting, enclosure integration, paper-handling configuration, printing formats, and host-system compatibility. Interface options, sensor configurations, and other modifications should be confirmed against the final project specifications.
| Mechanism： | CAPD245 | ||
| Printing method | Thermal dot line printing | ||
| Dots/line | 384 dots/line | ||
| Dot pitch | 8 dot/mm | ||
| Paper width | 58 mm | ||
| Printing width | 48 mm | ||
| Paper thickness | 54~91 um | ||
| Printing speed | 150 mm/s | ||
| Paper loading | Paper auto loading | ||
| Sensors | Head temperature | Thermistor | |
| Paper press shaft | Mechanical switch | ||
| Paper end | Photo interrupter | ||
| Font size | ASCII:9*17;12*24; Chinese: 24*24 | ||
| Power supply | Logic circuit | 2.6~3.6 V | |
| Motor | 4.75 ~9.5 V | ||
| Reliability | Circuit: over 1,000,000,000 pulses Cutter: over 7,000,000 cuts Thermal head: over 100 km MCBF: 37,000,000 lines | ||
| Ambient environment | Work temperature | -10 ℃~50℃ | |
| Work humidity | 20~85% RH | ||
| Storage temperature | -25℃~70℃ | ||
| Storage temperature | 10~90% RH | ||
| Dimension (L*W*H) | 127*89*93 mm | ||
| Weight | 0.45 kg | ||
| Interface | RS-232 /USB | ||
| power supply | DC 9~24V/2.5A | ||
| Command set | ESC/POS | ||
| Barcode | supported | ||
| Firmware location | 2 M NV Flash memory | ||
| Buffer | 4 KB | ||
| SRAM | 20 KB | ||
| Driver | USB driver | ||
| System | Windows/Linux/Android OS | ||
| Accessories: | paper near end sensor; | ||
| Paper roll holder | |||
| Paper bezel (paper guide mouth) | |||
| Interface connector | |||
| Power supply unit | |||
| Cable | |||
