MS-D245
Masung
Supporting 58 ± 0.5 mm paper, this 2 inch thermal printer module provides a maximum printing width of 384 dots (48 mm). Its compact W127 × D90 × H103 mm structure makes it suitable for integration into space-constrained self-service and industrial equipment.
The thermal printing module uses linear thermal technology with 300 dpi resolution and a maximum speed of 100 mm/s. It can produce clear text, graphics and other printed information for receipts, tickets, transaction records and equipment-generated documents.
The integrated thermal printer cutter supports both full-cut and half-cut operation, allowing equipment manufacturers to select the appropriate output format for different applications. With a cutter life of up to 700,000 cuts, the thermal printer with auto cutter is designed for frequent automated printing.
Multiple sensors support stable operation, including print-head temperature sensing, lift-up detection and reflective infrared paper-out detection. The thermal receipt printer module operates from 12–24 V and supports an operating temperature range of -10°C to 50°C, making it suitable for a range of embedded equipment environments.
This auto cut thermal printer can be integrated into self-service kiosks, POS equipment, ticketing machines, vending machines, parking systems, payment terminals, industrial control equipment and other automated devices that require compact receipt or ticket printing. It can function as a thermal receipt printer with auto cutter for receipts and transaction records, or as an embedded printer for tickets and operational documents.
As a manufacturer of thermal printer modules, Masung can discuss OEM and ODM requirements such as mechanical integration, mounting structure, paper-feed configuration, cutter requirements, communication interfaces, firmware, software integration, branding and packaging. For equipment requiring a thermal receipt printer auto cutter configuration or other customised embedded printing solution, specifications can be discussed according to the intended machine and application.
Specifications:
| Printing Method | Linear Thermal Printing |
| Resolution | 300 dpi |
| Printing Speed | 100 mm/s (max) |
| Printing Width | 384 dots (48 mm) |
| Paper Width/Thickness | 58 ± 0.5 mm / 56~105 μm |
| Paper Feeding Method | Automatic Paper Feed |
| Paper Cutting Method | Full Cut/Half Cut |
| Printing Length | 100 km |
| Cutter Life | 700,000 Cuts |
| Print Head Temperature | Temperature Sensor |
| Lift-up Detection | Microswitch |
| Paper Out Detection | Reflective Infrared Photoelectric Sensor |
| Operating Voltage | 12~24 V |
| Power Consumption | Average Current: 2.5 A |
| Transient Maximum Current | 6.0 A max |
| Operating Temperature | -10~50℃ (non-condensing) |
| Operating Humidity | 20%~85%RH (85%RH at 40℃) |
| Storage Temperature (240 hours) | ~20~60℃ (non-condensing) |
| Storage Humidity (240 hours) | 10%~90%RH (90%RH at 50℃) |
| Long-term Storage | 5~35℃, 40%~70%RH |
| Dimensions | W127mm×D90mm×H103mm |
