Masung MS-EP5860-300, Customizable Receipt/Ticekt Printer for Kiosk/Machine with High-Speed Printing
The key features of the MS-EP5860-300 embeddable printer for kiosk/machine:
1. Can accept paper rolls with a diameter of 80mm;
2. Compact size, easy installation;
3. Anti-clogging and anti-pull paper feed nozzle;
4. Side-opening cover for easy paper loading and maintenance;
5. Black mark and gap detection sensor functions (optional), suitable for various types of printing paper (ordinary thermal paper, black mark thermal paper, and gap-adhesive thermal paper);
6. New plastic stand, aesthetically pleasing, lightweight, and easy to install.
1. Can accept paper rolls with a diameter of 80mm;
2. Compact size, easy installation;
3. Anti-clogging and anti-pull paper feed nozzle;
4. Side-opening cover for easy paper loading and maintenance;
5. Black mark and gap detection sensor functions (optional), suitable for various types of printing paper (ordinary thermal paper, black mark thermal paper, and gap-adhesive thermal paper);
6. New plastic stand, aesthetically pleasing, lightweight, and easy to install.
| Quantity: | |
|---|---|
-
MS-EP5860-300
-
MASUNG
The MS-EP5860-300 is a high-performance 58mm embedded thermal printer designed for self-service kiosks. Its key advantage is a large 80mm paper roll capacity, significantly reducing the frequency of paper refills. This feature is essential for high-traffic environments, making it a top choice for custom applications like cinema and event ticketing.
Engineered for effortless operation, this printer ensures maximum uptime. A side-access cover allows for quick and convenient paper loading. Furthermore, its anti-blocking and anti-pull-out paper nozzle mechanism prevents jams and tampering, delivering reliable, uninterrupted performance that your customers can depend on.
The module offers exceptional media versatility with optional sensors. It can handle regular thermal paper, black mark paper, and gap-adhesive labels. This flexibility, combined with full or partial cutting options, makes it adaptable for a wide range of receipts, tickets, and stickers.
Designed for simple integration, the MS-EP5860-300 features a compact, lightweight build and standard interfaces like USB and RS-232. Its robust construction ensures a long print life of 100 km and reliable operation in various retail and kiosk environments, providing a durable and efficient printing solution.
Specifications:
| Printing method: | Line thermal printer |
| Dot matrix: | 640 dots |
| Resolution: | 300 DPI |
| Print speed: | 100 mm/s (max) |
| Print width: | 54.2 mm (max) |
| Paper width: | 58 mm/60 mm (depending on bracket) |
| Paper thickness: | 60 - 120 μm |
| Paper roll capacity: | 80 mm (max) |
| Paper feed: | Automatic paper suction/open-cover loading |
| Paper cutting: | Full cut/half cut |
| Print life: | 100 km |
| Print formats: | Highlight, underline, italic, bold, etc. |
| Cutter life: | 1 million cycles |
| Print baud rate: | 9600, 19200, 38400, 57600, 115200 |
| Operating voltage: | 24 ± 5% V |
| Average current: | 2 A @ 24 V |
| Peak current: | 5.5 A |
| Standard interfaces: | Power, RS232, USB |
| Special interfaces: | Cash drawer (occupies RS232) Interface) |
| Operating Temperature: | -10°C to 50°C (non-condensing) |
| Operating Humidity: | 20% to 85% RH (80% RH at 40°C) |
| Dimensions: | 154.9mm * 95.3mm * 52.4mm |
| Weight: | Approximately 0.40kg (excluding paper roll) |
