MS-FPT206
MASUNG
The MS-FPT206 is a compact 58mm thermal panel printer built for embedded applications with limited installation space. Its front frame is compatible with standard 80mm printer dimensions, making it an ideal drop-in replacement or upgrade path for existing kiosk designs. This reduces hardware modification costs and development time.
The printer supports easy paper loading, manual hand tearing, and optional paper cutting. Its straightforward paper path minimizes downtime during paper replacement in busy environments. With 58mm paper width, 60mm max roll diameter, and support for 60–100μm paper thickness, it ensures smooth, hassle-free paper handling.
The MS-FPT206 features a durable open-cover wrench with high shaft strength, ensuring reliable performance during frequent maintenance. Its elegant, compact design saves space while enhancing durability. Built for kiosk integration, it withstands continuous operation in commercial environments, offering a print length lifespan of 50KM.
For precise printing on pre-printed forms, the MS-FPT206 offers an optional black mark sensor for accurate paper positioning. It utilizes line dot thermal printing with 384 dots/line, 0.125mm dot pitch, and print speeds up to 80mm/s with 48mm effective print width. Paper-out detection and print head temperature monitoring ensure consistent output.
The Masung MS-FPT206 is widely used in cinema square terminals, ticket vending machines, queue management systems, retail kiosks, and automated service equipment. Its 58mm paper width and 80mm-compatible front panel suit businesses seeking a space-saving yet capable printing solution.
Customizable options include the optional black mark sensor for accurate positioning and adaptable paper cutting workflows. With interface options including cash drawer, parallel port, serial port, and USB, plus DC12～24V operating voltage, the MS-FPT206 can be tailored to virtually any kiosk or ticketing application.
| Model | MS-FPT206 |
| Printing Method | Line dot thermal printing |
| Dots Per Line | 384 dots/line |
| Dot Pitch | 0.125mm (8 dots/mm) |
| Paper Thickness | 60～100μm |
| Print Speed | 80mm/s (max) |
| Effective Print Width | 48mm |
| Max Paper Roll Diameter | 60mm (max) |
| Paper Width | 58mm |
| Paper Out Detection | Reflective infrared photoelectric sensor |
| Working Voltage | DC12～24V |
| Cutting Method | Manual tear |
| Operating Temperature | -10～50°C (non-condensing) |
| Operating Humidity | 20～85% RH (non-condensing) |
| Storage Temperature | -20～60°C (non-condensing) |
| Storage Humidity | 5～95% RH (non-condensing) |
| Print Length (Lifespan) | 50KM |
| Dimensions (L × D × H) | 115mm × 86.2mm × 132mm |
| Weight | 0.3Kg |
| Interface | Cash drawer, Parallel port, Serial port, USB |
