MS-CM-WSDM
MASUNG
MS-CM-WSDM_Ship Clock Log Telegraph Printer
MS-CM-WSDM is a ship clock engine telegraph record printer independently developed and produced by MASUNG. It can automatically recycle and save the printed records while printing, and can run for a long time. It has a special process that can complete printing in the ship's heavy water vapor and humid environment. The shaking of the ship does not affect the smooth operation of the printing. It also has serial port and RS232 interface for use.
| Model | MS-CM-WSDM |
| Printing method | Line point thermal printing |
| resolving power | 203dpi |
| Printing speed | 80mm/s(max) |
| Effective printing width | 72mm |
| Paper roll diameter that can be loaded | Outer diameter 42mm (max), inner diameter 12mm |
| Paper width | 80mm |
| interface | RS232 |
| working voltage | DC24V |
| Print length | 50KM |
| Panel height | 180.2mm |
| Panel width | 180.2mm |
| Embedding depth | 171.5mm |
| weight | 2.23kg |
| Paper cutting method | No paper cutting, paper printing recycling |
