Masung MS-SP701 Compact 58mm Thermal Printing Module for Kiosk & Terminal Receipts

Space-Saving All-in-One Design

The SP701 integrates the SOMT-15 printer mechanism with a self-developed control board and ARM-based solution. This integrated construction reduces the space required for the compact panel printer and can make mechanical and mould development more straightforward.

Measuring only 76.6 × 73.6 × 54.8 mm and weighing approximately 82 g, the micro printer can be integrated into compact terminals and equipment where installation space is limited.

300 DPI-Class Clear Printing

The panel thermal printer uses line thermal printing with 384 dots per line and a resolution of 8 dots/mm. It supports 58 mm paper with a 48 mm printable width and can print at speeds of up to 80 mm/s.

The control board supports ESC/POS commands, USB and serial communication, as well as common one-dimensional barcodes including EAN8, EAN13, CODE39 and CODE128. GB18030 Chinese character support is also available for applications requiring multilingual or Chinese text output.

Easy Paper Loading and Monitoring

Designed for practical equipment integration, the SP701 uses an easy paper-loading structure, allowing operators to replace paper without a complicated loading procedure. A photoelectric sensor detects paper-out conditions, while a thermal sensor monitors the print-head temperature.

Unlike a thermal panel printer equipped with an integrated cutter, the SP701 uses a cutter-free design. This configuration can be suitable when the application uses tear-off paper or has a separate cutting arrangement.

Reliable Embedded Operation

The SP701 is designed for continuous embedded printing, with a rated pulse life of 100 million pulses and a maximum printing length of 50 km. It operates at 0–50°C with 10–90% RH non-condensing humidity and supports 5 V ±10% and 8 V ±10% power configurations.

Its compact structure and low maintenance requirements make it suitable for equipment manufacturers looking for a dependable thermal embedded kiosk printeror other integrated printing solution.

Applicable Industries, Scenes and Scenarios

The SP701 can be used as an embedded printer in charging stations, portable printers, terminal equipment, handheld terminals, measurement systems, measuring instruments, data terminals, medical equipment and taxi meters. It can also serve as a 58mm panel printer for self-service and industrial devices where compact dimensions, easy paper loading and reliable thermal output are required. For applications specifically requiring an 80mm thermal embedded printer, a different Masung model with wider paper support would be more appropriate.

OEM & ODM Customisation

As a manufacturer of embedded printing solutions, Masung can discuss OEM and ODM requirements for the SP701, including mechanical integration, mounting structure, communication interfaces, firmware and software integration, branding and packaging. For equipment manufacturers developing a customised thermal printing module, Masung can also discuss application-specific requirements based on installation space, paper specifications, interface configuration and the intended operating environment.
