MS-7160
MASUNG
As an embedded barcode scanner, the MS-7160 is designed for applications requiring reliable mobile phone barcode recognition. Its 640 × 480 image sensor, white 6500K LED and ≥5 mil accuracy support efficient scanning, while its optimised illumination algorithm helps improve performance when smartphone screens have limited backlighting.
The MS-7160 functions as an Embedded 1D & 2D code reader and Embedded 1D & 2D code scanner, supporting PDF417, Data Matrix, QR Code and a wide range of 1D symbologies, including UPC, EAN, Code 128, Code 39 and GS1 DataBar. Its 80° diagonal viewing angle and ≥2 m/s motion tolerance help support fast scanning in automated equipment.
Designed as an embedded barcode reader, the MS-7160 measures 77.8 × 74 × 47 mm and weighs approximately 75 g, making it suitable for integration into compact equipment. TTL/RS-232, USB, USB COM, TTL 3.3V and TTL 5V interfaces provide flexibility for different host systems and customised equipment designs.
The MS-7160 embedded QR code scanner features an ultra-transparent tempered glass cover designed to resist scratches and maintain imaging quality during regular use. It operates from -20°C to +60°C, supports ambient lighting from 0 to 100,000 lux, and can withstand a 1.2 m drop onto concrete, making it suitable for demanding fixed-mount installations.
The MS-7160 is suitable for barcode scanner for kiosk applications including turnstiles, access control systems, self-service enquiry kiosks, queue management systems, medical self-service terminals and financial self-service equipment. It is particularly useful for mobile phone barcode scanning where compact integration, structural protection and reliable electronic-code reading are required.
Scanning Performance |
Model |
MS-7160 |
|
Image Sensor |
640×480 |
||
Lighting |
White LED(6500K) |
||
BarCode type |
2D |
PDF417, Data Matrix, QR Code ect. |
|
1D |
Interleaved 2 of 5, ISBN, Code 93, Code 11,UCC/EAN-128 GS1 Databar, Matrix 2 of 5, Industrial 2 of 5,Code 128, EAN-13, EAN-8, Code 39, UPC-A, UPC-E, Codabar,Standard 2 of 5, MSI-Plessey,GS1 composite code, ect. |
||
OCR(Optional) |
Comply to OCR-B (*customzed version) |
||
Accuracy |
≥5mil |
||
Field of View |
Alipay code |
40-450mm |
|
Wechat payment code |
35-450mm |
||
Symbol Contrast |
≥20% |
||
Barcode sensitivity |
Tilt ±55°,deflection ±55°,rotation 360° |
||
View angle |
Diagonal 80° |
||
Motion Tolearance |
≥2m/s |
||
Mechanical Parameters
|
Interface |
TTL/RS-232,USB,USB COM,TTL3.3V,TTL5V |
|
Dimension(mm) |
77.8(W)×74(D)×47(H)mm |
||
Weight |
75g |
||
Working Voltage |
DC 5V |
||
Rated Current |
500mA |
||
Environmental Parameters |
Working Temperature |
-20℃~+60℃ |
|
Storage Temperature |
-40℃~+70℃ |
||
Working Humidity |
5%~95%(no condensation ) |
||
Environment Lighting |
0~100,000LUX |
||
Thermal shock resistance |
Max Temperature |
60 °C (140 °F) |
|
Min Temperature |
-20 °C (-4 °F) |
||
Cycles |
30 minutes high temperature; 30 minutes low temperature |
||
Cycle |
24 |
||
Mechanical impact resistance |
Vibration |
2000 G, 0.7 ms, half sinus, 3 axes |
|
Drop Test |
Can withstand a 1.2-meter drop to the concrete floor |
||
Certificate |
|||
