Masung MS-HZ80, Kiosk Compact Embedded Thermal Printer for Self-Service Applications
Compact embedded thermal printer compatible with 58mm and 80mm tickets, ideal for kiosks and self-service systems.
Features easy paper loading, front-open panel, and sliding automatic cutter for unattended operation.
Supports high-speed printing (120 mm/s) and multiple barcode types, including EAN8, EAN13, CODE39, CODE128, and QR codes.
Multiple interfaces (USB and RS232) and a long-lasting design with 100 km mechanical life.
Features easy paper loading, front-open panel, and sliding automatic cutter for unattended operation.
Supports high-speed printing (120 mm/s) and multiple barcode types, including EAN8, EAN13, CODE39, CODE128, and QR codes.
Multiple interfaces (USB and RS232) and a long-lasting design with 100 km mechanical life.
| Quantity: | |
|---|---|
-
MS-HZ80
-
MASUNG
The MS-HZ80 58/80MM Kiosk Thermal Printer is a versatile embedded printing solution designed for self-service applications such as hotel check-ins, medical billing, and ticketing kiosks. Its compact panel-style design allows front-opening access, easy paper loading, and a small footprint, making it convenient to integrate into automated systems.
Equipped with a sliding automatic cutter, the MS-HZ80 eliminates paper jams and ensures smooth half-cut or full-cut operation, making it an ideal choice for unattended printing environments. The printer also features paper-out sensors and a temperature-controlled thermal print head for reliable, high-quality printing.
The printer supports high-speed line thermal printing at 120 mm/s, with a print width up to 72 mm and a resolution of 8 dots/mm. Its control board supports a wide variety of barcodes and QR codes, enabling versatile labeling and ticketing capabilities for a range of industries.
Built for durability and long-term performance, the MS-HZ80 can print up to 100 km of paper with a mechanical cutter life of 1 million cuts. With both USB and RS232 serial interfaces, it offers flexible connectivity for kiosks, POS systems, and other embedded self-service applications.
Specifications:
| Model | MS-HZ80 |
|---|---|
| Printing Method | Line thermal printing |
| Paper Width | 80 mm, 58 mm |
| Paper Feed Speed | 120 mm/s (max) |
| Dot Density | 8 dots/mm |
| Dots per Line | 576 dots/line |
| Print Width | 72 mm (max) |
| Paper Feeding Method | Easy-load paper |
| Print Length | 100 KM |
| Cutter Type | Sliding cutter |
| Cutting Mode | Half-cut, full-cut |
| Paper Thickness | 60–120 μm |
| Cutter Life | 1,000,000 cuts |
| Paper-Out / Last Sheet Detection | Reflective optical sensor |
| Print Head Temperature | Thermal resistor |
| Operating Voltage | DC 24V ± 10% |
| Average Current | 3A (25% printing dots) |
| Peak Current | 6.5A |
| Operating Temperature | -10 ~ 50°C (non-condensing) |
| Operating Humidity | 20% ~ 85% RH (at 40°C, 85% RH) |
| Storage Temperature | -20 ~ 60°C (non-condensing) |
| Storage Humidity | 10% ~ 90% RH (at 50°C, 90% RH) |
| Weight | Approx. 0.90 kg (without paper roll) |
| Interface | Serial (RS232), USB |
| Mechanical Life | 100 km |
| Max Paper Roll Diameter | 80 mm |
| Dimensions (W×D×H) | 131.2 × 62.6 × 107 mm |
The MS-HZ80 58/80MM Kiosk Thermal Printer is a versatile embedded printing solution designed for self-service applications such as hotel check-ins, medical billing, and ticketing kiosks. Its compact panel-style design allows front-opening access, easy paper loading, and a small footprint, making it convenient to integrate into automated systems.
Equipped with a sliding automatic cutter, the MS-HZ80 eliminates paper jams and ensures smooth half-cut or full-cut operation, making it an ideal choice for unattended printing environments. The printer also features paper-out sensors and a temperature-controlled thermal print head for reliable, high-quality printing.
The printer supports high-speed line thermal printing at 120 mm/s, with a print width up to 72 mm and a resolution of 8 dots/mm. Its control board supports a wide variety of barcodes and QR codes, enabling versatile labeling and ticketing capabilities for a range of industries.
Built for durability and long-term performance, the MS-HZ80 can print up to 100 km of paper with a mechanical cutter life of 1 million cuts. With both USB and RS232 serial interfaces, it offers flexible connectivity for kiosks, POS systems, and other embedded self-service applications.
Specifications:
| Model | MS-HZ80 |
|---|---|
| Printing Method | Line thermal printing |
| Paper Width | 80 mm, 58 mm |
| Paper Feed Speed | 120 mm/s (max) |
| Dot Density | 8 dots/mm |
| Dots per Line | 576 dots/line |
| Print Width | 72 mm (max) |
| Paper Feeding Method | Easy-load paper |
| Print Length | 100 KM |
| Cutter Type | Sliding cutter |
| Cutting Mode | Half-cut, full-cut |
| Paper Thickness | 60–120 μm |
| Cutter Life | 1,000,000 cuts |
| Paper-Out / Last Sheet Detection | Reflective optical sensor |
| Print Head Temperature | Thermal resistor |
| Operating Voltage | DC 24V ± 10% |
| Average Current | 3A (25% printing dots) |
| Peak Current | 6.5A |
| Operating Temperature | -10 ~ 50°C (non-condensing) |
| Operating Humidity | 20% ~ 85% RH (at 40°C, 85% RH) |
| Storage Temperature | -20 ~ 60°C (non-condensing) |
| Storage Humidity | 10% ~ 90% RH (at 50°C, 90% RH) |
| Weight | Approx. 0.90 kg (without paper roll) |
| Interface | Serial (RS232), USB |
| Mechanical Life | 100 km |
| Max Paper Roll Diameter | 80 mm |
| Dimensions (W×D×H) | 131.2 × 62.6 × 107 mm |
