Embedded Panel Thermal Printer For Pump Self Service Fuel Dispenser

The key features of the fuel printer:

  • High-speed line thermal printing at up to 150 mm/s with 203 dpi resolution for clear, reliable output
  •
  • Supports multiple 1D barcodes (EAN8, EAN13, CODE39, CODE128) and QR codes for versatile applications
  •
  • Easy paper loading design with paper-out detection, reducing maintenance and downtime
  •
  • Wide voltage support (12V–24V) and RS232/USB interfaces for flexible system integration
  •
  • Compact, durable print module ideal for queue machines, POS systems, kiosks, and industrial equipment
Availability:
Quantity:
Inquire Add to Basket

  • MS-FPT201P

  • Masung

4MASUNG independently developed 58mm thermal micro printer MS-FPT201
1. New line thermal printer
2. It has the characteristics of easy loading paper and easy maintenance
3. Support the printing of multiple barcodes, including the printing of multiple one-dimensional barcodes, and the printing of two-dimensional barcodes
4. Application scenarios: queuing machines, POS machines, gas station equipment and medical registration and payment equipment




Model MS-FPT201P
Resolution 203dots
Paper Width 58±0.5mm
Working Voltage 12~24 V
Dimension 100.1mm*55.8mm*99.8mm(L*W*H)
Hole D96.4mm*W95.5mm
Interface Serial(RS-232C/TTL) or USB
Paper Cutting Method Full/Partial (controlled by commands)
MS-FPT201 250g(without paper roll)
MS-FPT201K 270g(without paper roll & key)
