MS-150
MASUNG
Generate a short title for each of the paragraph below: The MS-150 Portable Thermal Transfer Label Printer is designed for applications where users need to print labels and small signs away from a desktop workstation. It is suitable for electrical equipment identification, energy meter labels, switch labels, meter box labels, safety warnings, maintenance tags, and other industrial marking applications.
With a 50mm/s print speed, 54mm paper width, and 48mm printable width, the MS-150 can handle a variety of narrow labels and small-format signs. Automatic paper feeding and button-controlled paper feeding make media handling simple, while the compact 205 × 106 × 78mm design and 0.725kg net weight make the printer convenient to carry between work areas.
The printer uses a special resin-based ribbon for thermal transfer printing, helping produce labels with clear and durable markings. With optional 300 DPI resolution, it can support applications requiring finer text, symbols, graphics, or other detailed information. The MS-150 is compatible with thermal label media and can support label thicknesses from 0.05mm to 0.15mm.
Designed for mobile operation, the MS-150 features a 2600mAh lithium battery and supports USB 5V charging. A fully charged battery can provide approximately 150–180 meters of printing at 12.5% printing density, while the power-bank function provides additional convenience for field applications. Bluetooth connectivity supports wireless printing from mobile devices, making the MS-150 a practical solution for technicians, installers, maintenance teams, and industrial users.
| Specification | Details |
|---|---|
| Model | MS-150 |
| Product Type | Portable Thermal Transfer Label Printer |
| Printing Method | Thermal Transfer |
| Resolution | 203 DPI; optional 300 DPI |
| Print Speed | 50 mm/s |
| Paper Width | 54 mm |
| Printable Width | 48 mm |
| Printable Thickness | 0.05–0.15 mm |
| Paper Feed | Automatic paper feeding; button-controlled feeding |
| Consumables | Thermal label paper |
| Ribbon Type | Special resin-based ribbon |
| Interface | Micro USB, Bluetooth, optional 2.4G Wi-Fi |
| Battery Capacity | 2600 mAh |
| Charging Method | USB 5V charging |
| Fully Charged Printing | Approx. 150–180 m at 12.5% printing density |
| Power Bank Function | Supported |
| Cutter | Hand-tear paper |
| Dimensions | 205 × 106 × 78 mm |
| Net Weight | 0.725 kg |
| Operating Temperature | 0°C–45°C |
| Mobile Printing | Supported via Bluetooth |
| Typical Applications | Electric symbols, warning labels, energy meter labels, switch labels, meter box labels, maintenance tags, and small industrial signs |
