Auto Sense USB QR Code Scanner Kiosk for Vending Machine

QR code scanner MS-7160
MASUNG embedded scanning module
1. Fully read all mainstream one-dimensional, two-dimensional codes, and barcode direct transmission of information in multiple languages
2. Object self induction, 2M/S motion tolerance
3. Built in RS232 and USB interfaces, can be switched by scanning the code
4.3.3-5 V wide voltage input, fearless of voltage fluctuations
5. Large scanning window+ultra-thin baking paint fashionable design
6. Rapid reading of paper and electronic screen codes by hand
Availability:
Quantity:
  • MS-7160

  • MASUNG

Features:

7160 scanner adopts CMOS global exposure image sensor, which supports the reading in the process of movement and is fully compatible with the mainstream 1D and 2D code. Support paper bar code and electronic screen bar code at the same time.

There is a buzzer and indicator light to indicate the successful scan. The appearance is clean and delicate, which can be embedded or external.

1. Fully read all the mainstream 1D, 2D code, multi-language information bar code direct transmission;

2. Object self-induction, 2M/S motion tolerance;

3. Built-in RS232 and USB interface, which can be switched by scanning;

4. 3.3-5v wide voltage input, no fear of voltage fluctuations;

5. Large scanning window and ultra-thin baking paint fashion design;

6. Speed reading manual paper and electronic screen code;

7. Support bar code reading without backlight;

8. Large scanning window + ultra-thin fashion design;

9. Extremely fast reading of hand paper and electronic screen code, high motion tolerance, supporting 10 recognition per second.


Omni Directional Reading for all 1D/2D Barcodes

Features:
* Object Auto Sense.

* Build in RS232 and USB Interface.

* Omni Directional Reading for all 1D/2D Barcodes.

* Can Read Paper&Barcode on Screen Even
Without Backlight from Cellphone.

* Multiple Language Barcode Message Transfer.


Applications: Access control ,gates,parking lot charges,lockers,financial,medical self-service machines,self-service vending cabinets,medical queue,lottery,cinema self-service ticket machine, scan code direct billing, mobile payment,bus scanning,and subway gates,library self-service terminal,etc.


Model: MS-7160
Physical Characteristics
Dimensions: 77.5mm x 66mm x 45mm
Weight: 75g
Voltage:   3.3-5 VDC
Current: 200mA
Performance Characteristics
Image (Pixels): 640 pixels (H)x 480 pixels (V)
Light Source: Illumination:6500K LED
Interfaces Supported: USB, RS232
Motion Tolerance s: >2m/s
1-D: UPC, EAN, Code 128, Code 39, Code 93, Code 11, Matrix 2 of 5, Codabar Interleaved 2 of 5, Mis Plessey, GSI DataBar, China Postal, Korean Postal
, etc
2-D: PDF417, MicroPDF417, Data Matrix, Maxicode, QR Code, MicroQR, Aztec
Hanxin, etc.
Minimum Resolution: ≥3.9 mil
Operating Temperature: -40°C to 70°C


MS-7160英文详情页
