ast 1D & 2D Barcode Scanning
As a desktop QR code scanner and versatile barcode scanner, the MS-7300 supports a broad range of 1D and 2D symbologies, including QR Code, MicroQR, Data Matrix, PDF417, UPC, EAN, Code 128, Code 39 and GS1 DataBar. With ≥4 mil accuracy and a 640 × 480 image sensor, it provides reliable code recognition for everyday scanning tasks.
Reliable QR and Barcode Reading
The MS-7300 works as a QR and barcode scanner, QR code reader and barcode reader for both printed and electronic codes. It supports a typical depth of field from 0–60 mm for 7 mil Code 39 and 0–130 mm for 30 mil QR codes. Its ±60° tilt and deflection tolerance and 360° rotation sensitivity provide flexible scanning from different angles.
High-Speed Scanning of Difficult Codes
Designed as a QR code barcode scanner and scanner barcode reader, the MS-7300 can recognise challenging codes that may be difficult for conventional scanners to capture. Its optimised algorithm and fill-light structure help read high-density, reflective, damaged, stained and wrinkled barcodes, while 2 m/s motion tolerance supports scanning of products in movement.
Desktop Design and Flexible Connectivity
The QR code scanner desktop design is suitable for integration into desktop retail and medical equipment. Measuring 150 × 95 × 98 mm and weighing 295 g, the scanner supports RS-232, USB and USB COM interfaces. It operates at DC 5V and supports ambient lighting from 0 to 100,000 lux, with a 1.2 m drop resistance for added durability.
Applicable Industries, Scenes and Scenarios
The MS-7300 desktop laser scanner is suitable for new retail, supermarkets, self-service checkout, desktop retail equipment, medical self-service equipment, pharmacies, hospitals, logistics counters and other automated scanning scenarios, particularly where products or documents need to be scanned quickly or where barcodes may be reflective, wrinkled, stained or partially damaged.
Specifications:
Performance | Image sensors | 640 x 480 CMOS |
Illumination | Red light LED |
Symbologies | 2D | QR Code, Data Matrix, PDF417，Han Xin Code，MaxiCode ，Aztec etc |
1D | UPC-A, UPC-E, EAN-8, EAN-13, ISBN, Code 128, GS1 128, ISBT 128, Code 39, Code93,Code 11, Interleaved 2 of 5, Industrial 2 of 5,Matrix 25, Standard 25, Codabar, MSI/MSI PLESSEY, GS1 DataBar, etc |
Resolution | ≥4.5mil |
Depth of field | Code 128 (10mil) | 70mm-175mm |
QE (20mil) | 20mm-160mm |
EAN13 (15mil) | 20mm-155mm |
| DM (15mil) | 30-155mm |
Symbol Contrast | ≥20% |
Scan Angle | Skew ±60°,Pitch ±60°,Roll 360° |
Field of View | 47°(H) X 37°(V) |
Motion tolerance | ＞2m/s |
Physical | Interface | USB , RS232( Optional) |
Dimensions (mm) | 150mm x 85mm x 85mm |
Weight | 320g |
Operating voltage | DC 5V |
Rated Current | 500mA |
Environmental | Operating temperature | -20℃~+60℃ |
Storage temperature | -40℃~+70℃ |
Humidity | 5%~95%（ non-condensing ） |
Ambient light | 0~100,000LUX |
Sealing | IP52 |
| Drops | 1.2m |
