Custom Embedded Thermal Receipt Printer 80 mm for Small Business and Commerce
Kiosk thermal transfer POS ticket label printer supports barcode printing.
1. Custom thermal printer with interface form: serial port, USB port.
2. Downloadable free river supports: XP/Win7/WIN8 (32-bit and 64-bit).
3. The barcode printer machine supports one-dimensional barcodes such as CODE 93 and CODE128 and two-dimensional barcodes PDF417 and QRCODE.
4. Anti-blocking and anti-pull function: pull the printing paper toward the paper outlet, and the printer flashes and cuts the paper and reports to the host.
When the paper outlet is blocked, the printing process stops, and the printer flashes and reports to the host of the error. When the paper outlet is not blocked, printing is resumed and continues.
| Quantity: | |
|---|---|
-
MS-D347-TL
-
MASUNG
More about the Commercial Pos Thermal Receipt Printer 80 mm Ideal for Kiosk Vending Machine:
The MS-D347-TL is an advanced 80mm auto-cutting thermal printing module that integrates:
Imported Japanese Seiko CAPD347 print mechanism (high-precision movement).
Proprietary MS-D347-TL control board (optimized for seamless performance).
Durable sheet metal structure (enhanced stability and longevity).
Key Features & Innovations.
✅ Space-Saving Design
Compact ARM-based control board embedded within the print mechanism.
Reduces installation footprint while improving mechanical reliability.
✅ Smart Printing Functions
Auto paper feeding & cutting (full/half-cut options).
Real-time detection systems:
Paper-out sensor.
Black mark tracking.
Anti-jam & anti-pull mechanisms.
Paper ejection monitoring.
✅ Seamless Integration
Unified hardware/software interfaces for easy compatibility.
Expandable with customizable add-ons (e.g., paper-end alerts, enhanced ejectors).
✅ Robust Performance
Precision-engineered for consistent, high-speed output.
Sleek, modern design suited for kiosks, POS systems, and industrial applications.
Why Choose the MS-D347-TL?
Japanese Seiko reliability + proprietary control technology.
Plug-and-play adaptability with minimal installation space.
End-user optimized for smooth, trouble-free operation.
MASUNG PRINTER
MS-D347-TL | Model： | MS-D347-TL |
| Printing method： | Line dot thermal printing |
| Resolution： | 203DPI |
| Print speed： | 150mm/s(max) |
| Print width： | 72mm |
| Paper roll outer diameter： | 120mm(max) |
| Paper thickness: | 56 - 105μm |
| Dimensions (including paper outlet): | W207.3mm×D121.5mm×H127.2mm |
| weight: | Approx. 1.2kg |
| Operating temperature: | -10-50°C (no condensation) |
MASUNG brand is founded in 2006, it is a scientific and innovative high-tech enterprise in China mainly dominated in receipt printers and scanners and providing diversified,intelligent and customized one-stop solutions for customers. Masung mainly service for four major fields: intelligent self-service terminals,new retailing,government affairs and industrial automation system. Serving global customers with the corporate values of "professionalism, innovation,integrity and service " At present,we have 8 subsidiaries ,2 R&D teams and more than 320 employees,including 80 R&D staffs.
MASUNG is located in Shenzhen and Changsha, China, with an office area of 4,000 square meters and a production area of 40,000 square meters. Adhering to R&D as the main task, relying on a high-level talent team and excellent innovative technology, we provide the entire industry chain service from SMT,assembly to aging test. Masung owned 100% of Independent Product Intellectual Property,there are more than 200 patents of Invention,Soft and continued to increase.Masung has passed ISO9001:2015,and all products certificated with CCC,energy saving,CE,ROHS,FCC,UL etc.Masung are delicated to provide ODM/OEM one-stop solutions to customer.
Products of Masung are widely used in scanning and printing fields such as medical treatment, transportation, government affairs, outdoor signs, finance, convenience terminals, cinemas, self-service cash registers, and supermarkets. We sincerely welcome agents and distributors from all over the world to have a visit and for win-win cooperation in the future.
More about the Commercial Pos Thermal Receipt Printer 80 mm Ideal for Kiosk Vending Machine:
The MS-D347-TL is an advanced 80mm auto-cutting thermal printing module that integrates:
Imported Japanese Seiko CAPD347 print mechanism (high-precision movement).
Proprietary MS-D347-TL control board (optimized for seamless performance).
Durable sheet metal structure (enhanced stability and longevity).
Key Features & Innovations.
✅ Space-Saving Design
Compact ARM-based control board embedded within the print mechanism.
Reduces installation footprint while improving mechanical reliability.
✅ Smart Printing Functions
Auto paper feeding & cutting (full/half-cut options).
Real-time detection systems:
Paper-out sensor.
Black mark tracking.
Anti-jam & anti-pull mechanisms.
Paper ejection monitoring.
✅ Seamless Integration
Unified hardware/software interfaces for easy compatibility.
Expandable with customizable add-ons (e.g., paper-end alerts, enhanced ejectors).
✅ Robust Performance
Precision-engineered for consistent, high-speed output.
Sleek, modern design suited for kiosks, POS systems, and industrial applications.
Why Choose the MS-D347-TL?
Japanese Seiko reliability + proprietary control technology.
Plug-and-play adaptability with minimal installation space.
End-user optimized for smooth, trouble-free operation.
MASUNG PRINTER
MS-D347-TL | Model： | MS-D347-TL |
| Printing method： | Line dot thermal printing |
| Resolution： | 203DPI |
| Print speed： | 150mm/s(max) |
| Print width： | 72mm |
| Paper roll outer diameter： | 120mm(max) |
| Paper thickness: | 56 - 105μm |
| Dimensions (including paper outlet): | W207.3mm×D121.5mm×H127.2mm |
| weight: | Approx. 1.2kg |
| Operating temperature: | -10-50°C (no condensation) |
