QR code scanner MS-2104
Meisong fixed self sensing QR code scanning module
1.84 ° wide-angle camera, 360 ° all-round barcode capture and acquisition
2. Add a solar filter for normal reading under sunlight
Both paper and electronic screens, as well as one-dimensional and two-dimensional barcodes, can be read
4. Split type, easy to integrate, with a total thickness of less than 1cm, 37 * 19 * 7mm light and thin height integration
5. Supports interfaces such as RS232, USB, USB virtual serial port, TTL, etc
6. Support multiple scanning methods such as self sensing object scanning, trigger scanning, command scanning, constant light scanning, mobile screen scanning, etc
The fixed two-dimensional scanning module MS-2104 of Masung uses a wide-angle lens for scanning, suitable for close range reading, supports paper and electronic screens, supports full code barcode reading, and adds a filter algorithm under sunlight, which is very suitable for access control and applications under sunlight. It comes with a supplementary light, without the need for additional equipment. The lens and decoding board are separated, with a thickness of less than 1cm, and the structure is more flexible, which is very suitable for the design of ultra-thin structural components. The rich interface types are compatible with USB, RS232485, TTL3.3/5V, Wigan; Wide voltage design 3.3-16V, wide temperature design, supporting use in environments ranging from -30 to 70 ℃
Model
| MS-2104 |
| Collection method | Imaging, CMOS Sensor |
| Collection speed | 1/60 秒 |
| Field of view angle | Diagonal 84 °, horizontal 72 °, vertical 54 ° |
| Recognition accuracy | Two dimensions ≥ 7.5mil, one dimension ≥ 5mil |
| Support coding system | Compliant with international and domestic universal QR code standards: QR Code, Data Matrix, PDF417, Hanxin Code, etc. Compliant with international and domestic universal QR code standards: UPC-A, UPC-E, EAN-8, EAN-13, ISBN, Code 128, GS1 128, ISBT 128, Code 39, Code93, Code 11, Interleaved 2 of 5, Industrial 2 of 5, Matrix 25, Standard 25, Codabar, MSI/MSI PLESSEY, GS1 DataBar, etc |
| Supplementary light | white |
| Size (mm) | Lens plate: 43 * 10 * 3mm (length * width * height); Decoding board: 37 * 19 * 7mm (length * width * thickness) |
| weight | < 20g |
| Socket interface | 12PIN socket, 1.25mm pitch, industrial application socket, 12pin 0.5mm pitch FPC socket, compatible with both upper and lower power sources of 3-3.6V or 3.6-16V, optional 12PIN cable socket: USB serial port/USB KBW, RS232, RS485, 3.3V TTL/5V TTL 12PIN FPC socket: USB serial port/USB KBW, 3.3V TTL/5V TTL |
