MS-CH362
MASUNG
The MS-CH362 supports a media width of 110–320 mm and a printable width of up to 252 mm, making it suitable for applications that require larger safety labels and warning signs rather than standard narrow labels.
The printer uses resin, hybrid, or wax-based ribbons to create durable thermal transfer prints. Depending on the selected ribbon and substrate, printed text, symbols, and graphics can provide good resistance to scratching, fading, water, sunlight, and corrosion, making the MS-CH362 suitable for demanding signage applications.
Roll-fed automatic media feeding and the integrated cutter simplify continuous safety sign label printer workflows. Operators can design the required sign on a computer, send it through the USB interface, and automatically cut the finished sign after printing.
The MS-CH362 can work with roll label materials, perforated label media, PVC materials, laminated aluminium foil composite materials, aluminium alloy labels, and PVC logo sticker media within its supported specifications. This gives businesses greater flexibility when producing different types of industrial identification and safety signage.
With a net weight of approximately 28.6 kg, the MS-CH362 has a robust construction intended for factory and workshop environments. Its operating temperature range of 0°C to 40°C and relative humidity range of 20–70% RH, without condensation, support reliable operation in suitable indoor industrial conditions.
The Masung MS-CH362 is designed for businesses and organisations that need to produce wide, durable signs and labels on demand. Typical applications include:
Factory safety signage – Warning signs, hazard identification labels, equipment notices, and operating instructions.
Workshop and warehouse signs – Safety notices, area identification, storage warnings, and workplace labels.
Pipeline and industrial equipment marking – Identification labels, warning information, and equipment signage.
Outdoor safety and warning signs – Durable labels for suitable outdoor applications when the selected ribbon and substrate meet the environmental requirements.
Electrical and mechanical equipment – Equipment identification, warning symbols, operating instructions, and maintenance labels.
Custom industrial labels – Wide-format labels, logos, symbols, and other variable information produced directly from a computer.
The MS-CH362 can therefore serve as a safety signage printer, industrial label printer, warning sign printer, and wide-format thermal transfer printer for different production environments.
The MS-CH362 can be used as a base platform for OEM and ODM safety sign printing solutions. For projects with specific hardware, software, or integration requirements, Masung can discuss customization options according to the application and production environment.
| Model | MS-CH362 |
| Product Name | Wide format logo thermal transfer printer |
| Paper thickness | Label paper below 0.38mm, roll label paper, hole label paper,aluminum alloy label |
| Paper feeding method | Roll material, automatic induction paper feeding |
| Resolution | 300DPI |
| Print speed | 2inch/s |
| Paper width | 110mm-320mm |
| Printable Width | 10 inches (252 mm) |
| Communication interface | USB, Bluetooth connection (optional) |
| Working voltage and current | AC220V (±10%)、2A(max) |
| Operating temperature | 0℃-40℃(no condensation) |
| Working relative humidity | 20~70%RH(no condensation) |
| Storage temperature (whole machine) | -10~60℃(no condensation) |
| Net Weight | 28.6Kg |
| Dimensions | 526.2mm*471.96.05mm*267.7mm |
